NTRON 509FX
Part Number: 509FX
The N-TRON 509FX is a robust 9-port industrial Ethernet switch designed for harsh environments, enabling long-distance data transmission via fiber optic connectivity.
Description
N-TRON 509FX Technical Specifications
Network & Performance
- Ports: 8 x 10/100BaseTX (RJ-45) and 1 x 100BaseFX (Fiber Optic, available with ST or SC connectors)
- Data Rate: Auto-sensing 10/100 Mbps on RJ-45 ports; 100 Mbps on the fiber optic port.
- Throughput: Up to 1.8 Gb/s (Gigabits per second) maximum throughput.
- Switching Method: Store-and-Forward
- MAC Addresses: Supports up to 4,000 MAC addresses.
- Latency: Typically 2.1 µs (microseconds).
Power & Electrical
- Input Voltage: Redundant power inputs (10-30 VDC)
- Input Current: 260 mA @ 24 VDC
- Power Consumption: 21.3 BTU/hr @ 24 VDC
Environmental
- Operating Temperature: -40°C to 85°C (-40°F to 185°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
- Operating Humidity: 10% to 95% (non-condensing)
- Shock: 200 g @ 10 ms
- Vibration: 50 g, 5-200 Hz, triaxial
Physical
- Enclosure: Rugged industrial DIN-rail mountable enclosure
- Dimensions (approx.): * Height: 5.76 cm (2.27 inches)
- Width: 13.85 cm (5.45 inches)
- Depth: 8.74 cm (3.44 inches)
- Weight: 0.8 kg (1.6 lbs)
