Bently Nevada 3500/32

The Bently Nevada 3500/32 is a 4-Channel Relay Module, a vital component within the Bently Nevada 3500 Series Machinery Protection System. Here’s a breakdown of its key features and functions:

• Function:
  • It provides four independent relay outputs.
  • These outputs can be programmed to trigger alarms or other actions based on the monitoring data from the 3500 system.
  • It allows for the implementation of voting logic, where multiple monitoring points must reach a certain state before an alarm is triggered.
• 3500 Series Integration:
  • It’s designed to work seamlessly within the 3500 Series rack.
  • It can be placed in various slots within the rack, providing flexibility in system configuration.
• Key Features:
  • Programmable Alarm Drive Logic: Users can configure the relay outputs using AND/OR logic, incorporating alarm statuses from any monitor channel in the rack.
  • SPDT Relays: It utilizes single-pole, double-throw relays, providing versatile switching capabilities.
  • It is used to take the information that the 3500 series monitoring system provides, and create a physical electrical output, that can be used to trigger external devices.
• Applications:
  • It’s used in a wide range of industrial applications where machinery protection is critical, such as power generation, oil and gas, and petrochemicals.
  • It enables the integration of the 3500 system with external alarm systems, shutdown systems, and other control systems.
